Passive House Window

VEKA SOFTLINE MD82 casement system with 82mm system depth provides ultimate insulation performance.

An innovative 3-level center seal gasket design keeps out noise, cold, damp and strong wind. The MD82 features a specially designed, Uf optimized 7-chamber geometry for excellent thermal insulation. Custom-made steel reinforcements provide structural strength for large windows and combination windows, often used in high-rise buildings, but still enables a Uf of 1.0 W/m2·K including steel reinforcements. The glazing depth of 25mm adds extra insulation between glass and frames. In combination with high-performing glass this prevents water condensation on the inside of the window. The MD82 is the most advanced window system by VEKA. VEKA strongly believes, that Asia, especially colder regions in China, Korea and Japan, should have easy access to this high-performing window system. VEKA proudly extrudes this product line in China and is not just importing the profiles. MD82 is the first choice for projects which require an Uw of 0.8-1.3 W/m2·K and better including requirements for Passive Houses. VEKA’s MD82 window system is Passive House certified by the Passive House Institute of leading expert Dr. Feist and is certified to be used in “phB cold regions” including North China.

U-Value of standard window is from 0.80 to 1.50 as per different glass Configuration

Request A Quote

Custom Options

  • Material
  • Glass
  • Accessories
  • Downloads
  • uPVC

    System U1.0 W/m2.K (including steel reinforcements)

    System depth 82mm – 7 chambers

    Glazing width range from 22mm – 52mm

    Glazing depth 25mm

    High-performance 3-level center seal gasket system

    Available in profile wall thickness “Class A”

    Specially designed steel reinforcements for high wind-load

    PHI – Passive-House certified

There are lots of custom options for the glass from the type of glass, layer to the thickness and color. Our engineers will choose the best combination of the following based on your window style and budget.

For each window style, the accessories may come in differently. You can choose your accessories by brands or be advised by our experienced engineers.

There are multiple designs for this window style, please see the technical document below for more information.
